•Suitable for all wheel position of middle/long distance buses and steering wheel position of trucks on good road conditions.
•4 linear tread grooves provides excellent directional driving performance and prevents uneven tire wear.
| Benefits | Vehicle |
|---|---|
 |
 |
•Suitable for all wheel position of middle/long distance buses and steering wheel position of trucks on good road conditions.
•4 linear tread grooves provides excellent directional driving performance and prevents uneven tire wear.
| Size | Ply Rationg | Spd | Load Index (single/double) | Measure Rim (inch) | Max Load(kg) | Pressure(Kpa) | Inflated Dimensions | Tread Depth (mm) | Min. DualSpacin g (mm) | |||
| Single | Dual | Single | Dual | SW | OD | |||||||
| 11R22.5 | 14 | L | 144/142 | 8.25 | 2800 | 2650 | 720 | 720 | 279 | 1050 | 10.50 | 320 |
| 11R22.5 | 16 | L | 146/143 | 8.25 | 3000 | 2725 | 830 | 830 | 279 | 1050 | 10.50 | 320 |
| 11R24.5 | 14 | L | 146/143 | 8.25 | 3000 | 2725 | 720 | 720 | 279 | 1104 | 10.50 | 318 |
| 11R24.5 | 16 | L | 149/146 | 8.25 | 3250 | 3000 | 830 | 830 | 279 | 1104 | 10.50 | 318 |
| 295/75R22.5 | 14 | L | 144/141 | 9.00 | 2800 | 2575 | 760 | 760 | 298 | 1044 | 10.50 | 335 |
| 295/75R22.5 | 16 | L | 146/143 | 9.00 | 3000 | 2725 | 830 | 830 | 298 | 1044 | 10.50 | 335 |
| 285/75R24.5 | 14 | L | 144/141 | 8.25 | 2800 | 2575 | 760 | 760 | 283 | 1050 | 10.50 | 318 |
| 285/75R24.5 | 16 | L | 147/144 | 8.25 | 3072 | 2800 | 830 | 830 | 283 | 1050 | 10.50 | 318 |
| 315/80R22.5 | 20 | K | 157/154 | 9.00 | 4125 | 3750 | 900 | 900 | 312 | 1076 | 10.50 | 351 |
